Datasheet Firewall FPR3110-NGFW-K9
Hardware
Interfaces	8 x RJ45, 8 x 1/10G SFP+
Optional interfaces	10G SFP+
Maximum number of interfaces	Up to 24 total Ethernet ports, (8x1G RJ-45, 8x1/10G SFP, and network module)
Integrated network management ports	1x 1/10G SFP
Serial port	1x RJ-45 console
USB	1x USB 3.0 Type-A (900mA)
Storage	1x 900 GB, 1x spare slot
System Performance
Throughput: FW + AVC (1024B)	17.0 Gbps
Throughput: FW + AVC + IPS (1024B)	17.0 Gbps
Maximum new connections per second, with AVC	130,000
TLS	4.8 Gbps
Throughput: IPS (1024B)	17.0 Gbps
IPSec VPN Throughput (1024B TCP w/Fastpath)	8 Gbps
Projected IPSec VPN Throughput (1024B TCP w/Fastpath) with VPN Offload (FTD 7.2)	11.0 Gbps
Maximum VPN Peers	3,000
Local On-device Management	Yes
Centralized management	Centralized configuration, logging, monitoring, and reporting are performed by the Firewall Management Center or alternatively in the cloud with Cisco Defense Orchestrator
Application Visibility and Control (AVC)	Standard, supporting more than 4000 applications, as well as geolocations, users, and websites
AVC: OpenAppID support for custom, open source, application detector	Standard
Cisco Security Intelligence	Standard, with IP, URL, and DNS threat intelligence
Cisco Secure IPS	Available; can passively detect endpoints and infrastructure for threat correlation and Indicators of Compromise (IoC) intelligence
Cisco Malware Defense	Available; enables detection, blocking, tracking, analysis, and containment of targeted and persistent malware, addressing the attack continuum both during and after attacks. Integrated threat correlation with Cisco Secure Endpoint is also optionally available
Cisco Secure Malware Analytics	Available
URL Filtering: number of categories	More than 80
URL Filtering: number of URLs categorized	More than 280 million
Third-party and open-source ecosystem	Third-party and open-source ecosyste
High availability and clustering	Active/active, Active/standby. Cisco Secure Firewall 3100 Series allows clustering of up to 8 chassis
Cisco Trust Anchor Technologies	Secure Firewall 3100 Series platforms include Trust Anchor Technologies for supply chain and software image assurance. Please see the section below for additional details
Dimensions
H x W x D	1.75 x 17 x 20 in. (4.4 x 43.3 x 50.8 cm)
Weight	23 lb (10.5 kg) 1 x power supplies, 1 x NM, fan module, 1x SSD
Form factor (rack units)	1RU
Rack mountable	Yes. Fixed mount brackets optional. (2- post). Mount rails included (4-post EIA- 310-D rack)
Power
Power supply configuration	Single 400W AC, Dual 400W AC optional. Single/Dual 400W DC optional
AC input voltage	100 to 240V AC
AC maximum input current	< 6A at 100V
AC maximum output power	400W
AC frequency	50 to 60 Hz
Redundancy	1+1 AC or DC with dual supplies
Fans	2 hot-swappable fan modules (with 2 fans each)
Noise	65 dBA@ 25C 74 dBA maximum
Environment
Temperature: operating	32 to 104°F (0 to 40°C)
Temperature: nonoperating	-4 to 149°F (-20 to 65°C)
Humidity: operating	10 to 85% noncondensing
Humidity: nonoperating	5 to 95% noncondensing
Altitude: operating	10,000 ft (max)
Altitude: nonoperating	40,000 ft (max)
